At Haider Aluminium, based in Addis Ababa, Ethiopia, we are proud to introduce our high‑quality Aluminium 1050 Forgings, crafted to meet the needs of fabricators, machinery builders, and architectural specialists across the region. Each forging is carefully produced with precision and backed by our local expertise — giving you not just a component, but a partner in reliable supply and customer‑care. Whether for light structural members, decorative frames, or machinery parts, our Aluminium 1050 Forgings deliver consistency, workable strength and the responsiveness of a locally‑based manufacturer you can trust.
Our Aluminium 1050 Forgings are produced from a commercially‑pure aluminium alloy (minimum 99.5% Al) offering excellent corrosion resistance, high ductility, and easy workability. Typical mechanical properties include a tensile strength around ~90 MPa and yield strength near ~40 MPa, with elongations up to ~35% depending on temper. ucpcdn.thyssenkrupp.com+2mag.notzgroup.com+2 While this grade doesn’t deliver the high strength of alloyed series, its exceptional formability and conductivity make it ideal for precision forging, bending, welding and machining — enabling versatile components that balance lightweight design with dependable performance.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Haider Aluminium based in Addis Ababa, Ethiopia is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Haider Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@haideraluminium.com
Aluminium 1050 Forgings from Haider Aluminium find useful application wherever lightweight, corrosion‑resistant, and structurally sound forged parts are needed. They are ideal for decorative architectural elements such as framed canopies or façade extrusions, for light machinery housings, equipment brackets subject to welding and bending, and for fluid or air conduit support structures in benign environments. Their excellent formability means they can be shaped and finished with ease, while their corrosion resistance ensures durability in moderate conditions. With our local production and support, Ethiopian fabricators and engineers gain forged parts that perform well while staying close to home.
